Proximity Card Readers


DKS offers a full line of Proximity Card Readers in different mounting styles to meet your exact needs. The Readers are sealed in epoxy, making them vandal-resistant and are ideal for both indoor and outdoor applications.  We also offer Mifare Card Readers for those applications using Mifare Classic cards.


Proximity Card Readers

The 2″ to Long Range Entry Solution

DoorKing offers the following proximity card reader products:  DK Prox, HID and AWID proximity card readers, all of which are compatible with the 1830 Series access controllers. All readers feature a cosmetically appealing design that will blend with any architectural design and offer high durability and reliability.  Mifare card readers are also available for those applications using Mifare Classic cards (we do not sell the Mifare cards, just the Mifare card readers).

AVI (or Automated Vehicle ID) Long Range readers operate in the same manner as proximity card systems, but with longer ranges. A typical AVI system places a tag on the vehicle, rather than having the user carry it. In this manner, a gate system will open automatically as the vehicle approaches with a properly credentialed tag. This provides convenience and is ideal in applications where only authorized vehicles are allowed entry.

Have DKProx cards or Mifare cards that are un-usable because the card number has worn off?  A simple solution is to use the DK Card Identifier which allows you to read the card access code on your computer.

A Variety of Card & Tag Options Available



DKProx, HID, AWID &
MiFare Card Reader Options
Automatic Vehicle
Identification Option
Compatible Only with
1830 Series Systems



Applications

Apartment Complexes & College Residence Halls
Commercial & Industrial
Gated Communities
Maximum Security
Mixed Use Buildings
Parking Facilities
Self Storage

Product Features







License Plate

AVI (or Automated Vehicle ID) Systems operate in the same manner as Proximity Card Systems, but with longer ranges – up to 25 feet. A typical AVI System places a tag on the vehicle, rather than having the user carry it. In this manner, a gate System will open automatically as the vehicle approaches with a properly credentialed tag.







Windshield/Headlight AVI

Low visibility vehicle tag, the Headlight/Windshield Tag is designed to be used with the DKS 1815-350 Long Range Reader. The Tag does not contain a battery, so it never wears out.



%%tb-image-alt-text%%
Up to 25 Feet

AVI long range adjustable from 8 ft – 25 ft (3.6 m – 7.6 m). Includes Reader Control Box.

%%tb-image-alt-text%%
DK Prox Decal

The DK Dot turns your phone into an access credential with no apps. Add the DK Prox Dot to the back of your mobile device (inside the case).

%%tb-image-alt-text%%
Outdoor Use

For outdoor applications to control access to secure areas.

%%tb-image-alt-text%%
Indoor Use

For indoor applications to control access to secure areas.

Technical Specifications

Specifications
DK Prox Readers
  • 1815-300; up to 3-inch read range.
  • 1815‐301; up to 4-inch read range.
  • 1815‐302; up to 2-inch read range.  Fits inside 1830 90 Series telephone entry systems.
  • 1815‐305; up to 12-inch read range.
  • 1815‐330; 1815‐300 reader on a surface mount enclosure.
  • 1815‐333; same as 1815‐330 but also includes a 2358‐010 Tracker expansion board
  • 1504-124; 1815‐300 mounted on surface enclosure with built in intercom substation.
DK Prox Long Range (AVI) Reader
  • 1815-350: adjustable read range; 8 ft to 25 ft.
  • Two different operating modes: timing and trigger.
  • Uses frequency hopping technology in the UHF frequency band (902 – 928 MHz).
  • Adjustable timing intervals between consecutive readings of same tag.
  • Uses passive tags – no batteries to worry about.
  • Dual technology cards are available allowing a single card to be used with both AVI and standard DK Prox readers.
AWID Readers
  • 1815‐280 (SR 2400); up to 4‐inch read range.
  • 1815‐281 (SP 6820); up to 8‐inch read range.
  • 1815‐282 (MM 6800); up to 8‐inch read range.
  • 1815‐290; 1815‐280 reader on a surface mount enclosure.
  • 1815‐292; same as 1815‐290 but also includes a 2358‐010 Tracker expansion board.
  • 1504‐122; 1815‐281 mounted on surface enclosure with built in intercom substation.
  • 1815‐283 (MR 1824); up to 24‐inch read range. Includes regulated power supply.
  • 1815‐284 (MR 1824 MC); metal compensated; up to 16‐inch read range. Includes regulated power supply.
  • Long Range Vehicle Tag Reader
  • 1815‐170 (LR 3000).
  • 1815‐168 Installation Kit.
  • 1815‐162 Power Supply.
  • 1508‐072 Mounting Bracket.
  • Read range varies depending on the type of tag used. Maximum read range is 15 feet.
  • Installation kit is highly recommended for proper setup (AWID Policy.)
HID Readers
  • 1815‐380 (ProxPoint Plus); up to 3-inch read range.  Fits inside 1830 90 Series telephone entry systems.
  • 1815‐381 (MiniProx); up to 5-inch read range.
  • 1815‐382 (ThinLine II); up to 5-inch read range.
  • 1815-390; 1815‐382 reader on a surface mount enclosure.
  • 1815-392; same as 1815‐390 but also includes a 2358‐010 Tracker expansion board.
  • 1504‐123; 1815‐382 mounted on surface enclosure with built in intercom substation.
  • 1815‐395 (MaxiProx); Up to 6‐foot read range with 1508‐014 tags.
  • Includes regulated power supply.



Mechanical
  • Because physical contact is not required, proximity card readers can read card data through common building materials like: concrete, brick, stone, drywall, plaster, glass, wood, plastic…in fact, through anything but metal.
  • Proximity card readers are maintenance free.   There are no parts to wear out or adjust.
  • Passive card technology provides an unlimited number of “card reads” with no battery to wear out.
  • Passive cards, unless they are physically abused, will last virtually forever.
  • Clamshell, ISO Graphic and KeyTag type cards are available.
  • Read ranges are not absolute and will vary depending on several factors including where the reader is mounted, the mounting surface and product application.
  • These card readers output their data in 26-bit wiegand format.
  • Most card readers operate on 5-12 VDC.  AVI systems may operate at different voltages.
  • These card readers are not designed for stand-alone operation (see 1520/1524 readers) and must be connected to an access controller (DKS 1830 Series systems).
Electrical
PROXIMITY READERS Input voltage / current
1815-300: 12 VDC – 200mA
1815-301: 12 VDC – 200mA
1815-302: 12 VDC – 200mA

2 color LED (Red, Green), Piezo Beeper
Frequency: 125 kHz
Output Format 26-bit wiegand



AVI LONG RANGE READER Input voltage / current
1815-350: 12 VDC Regulated – 3.0 A

Frequency: 902-928 MHz
Output Format 26-bit wiegand
Operating Environment: -31°F to 149°F (-35°C to 65°C)





Dimensions and Weight





Dimensions and Weight
